Features
Durability:
- Powerful radial piston air motor provides reliable power and adjustable speed
- Rugged all-steel construction for maximum life
- Abrasion resistant sheathing over control hoses
- Sealed, automatic disc brake for sure operation and protection from moisture and contaminants
Safety:
- Full debris protection with drum and control guards
- Remote pendant control with variable speed and quick release/replace
Performance:
- 9.4 hp radial piston motor with ample torque and precise spotting control
- Quick check oil sight gauge on motor
- Quick release remote pendant control for remote operation
Model Specifications
Model | HP | Rated Capacity at Top Layer kg (lb) | Lifting Speed at Top Layer m/min (f/fpm) | Stall Pull kg (lb) | Air Consumption with Rated Load m³/min (ft³/min) | Travel Air Volume of Air Needed to Move Distance Shown Over 3 m (m³) | Travel Air Volume of Air Needed to Move Distance Shown Over 10 ft (ft³) | Sound Level as per EN 14492-1 dB(A) | Inlet Size NPT | Exhaust Size NPT | Net Weight kg (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|
FA2i | 9.4 | 2,000 (4,400) | 16 (51) | 4,154 (9,139) | 8 (280) | 0.3 | 10.8 | 87 | 1-1/4” | 1-1/4” | 386 (850) |
