Features
Durability:
- Standard stainless steel drum guard provides outstanding corrosion resistance and adjusts for multiple takeoff angles
- Marine grade paint on carbo-zinc blasted steel provides superior corrosion resistance
- All steel and stainless steel construction for long life
- Stainless steel braided and PTFE hoses provide superior corrosion resistance
- Steel Guards protect critical components mounted on the winch
Safety:
- Main air emergency stop protects personnel in case of emergency
- Internal upper and lower limit switches prevent raising or lowering past set limits
- Overload protection senses when tension exceeds capacity and prevents operation
- Lift-to-shift variable speed lever provides precise control and built-in safety
Performance:
- Precision variable speed motor provides reliable power in a rugged package for harsh environments
- Press roller and grooved drum assists with wire rope spooling
Model Specifications
Model | MR150K |
|---|---|
Motor Type | Gear Air Motor |
Rated Capacity at Top Layer 2nd Layer kg (lb) | 150 (330) |
Line Speed m/min (fpm) | 30 (98) |
Max. Rope Storage Capacity 5 Layers (w/10 mm rope) m (ft) | 180 (591) |
Working Rope Storage Capacity 2nd Layer (w/10 mm rope) m (ft) | 55 (180) |
Drum Length mm (in) | 300 (11.8) |
Air Consumption with Rated Load m3/min (ft3/min) | 2.5 (88) |
Net Weight kg (lb) | 210 (465) |
