Features
- High Inlet Air Temperature Operation: Accommodates inlet air temperatures up to 200°F (94°C) and are ideal for use with compressors that do not include built-in aftercoolers.
- Lower Cost of Ownership:Â Efficient heat exchangers, a built-in stainless steel demister that removes all moisture and a fully adjustable programmable electronic drain valve reduce energy use and minimize air loss
- Built-in Reliability: Corrosion-resistant heat exchangers, an enhanced control-system and high-efficiency moisture-separation ensure a steady long-term supply of dry air
- Smart Control:Â Easy to use, advanced microprocessor control that lets you easily adjust and manage system parameters
- Consistent Clean, Dry Air:Â Variable-speed fans reduce power consumption when units operate at less than maximum cooling capacity, while ensuring a consistent dew point
Specifications
Model Capacity m³/hr (scfm) Operating Power kW Length x Width x Height mm (in) Weight kg (lb) Connection Air In/Out D25IT 25 (15) 0 500 (20.0) x 386 (15.5) x 661 (26.0) 38 (84) 1/2″ NPT D42IT 42 (25) 0 500 (20.0) x 386 (15.5) x 661 (26.0) 39 (86) 1/2″ NPT D60IT 60 (35) 0 500 (20.0) x 386 (15.5) x 661 (26.0) 39 (86) 1/2″ NPT D102IT 102 (60) 0 567 (22.5) x 420 (16.5) x 771 (30.5) 57 (126) 3/4″ NPT D140IT 140 (82) 1 567 (22.5) x 420 (16.5) x 771 (30.5) 62 (137) 3/4″ NPT D170IT 170 (100) 1 567 (22.5) x 420 (16.5) x 771 (30.5) 67 (148) 1″ NPT
