Features
Infinite Speed Control
Move up and down by action on the handle and as fast or slow as the operator chooses to move. Ideal for both highspeed lifting applications and slow and precise movements.
Ultra-high Speed
Lifting speed up to 40 m/min (131 ft/min), 2 times faster than traditional lifting equipment, significantly improving productivity while ensuring operator safety.
Precise Positioning
Provide millimeter accuracy with lifting speed of less than 0.3 m/min (1 ft/min), ensuring the operator precise control in manipulating or assembling delicate or fragile parts.
Full Stroke Float
With a minimum force of 250 grams on the load, the operator can precisely orient the load throughout the full stroke range by manipulating the load directly with hands.
Safety Alternative
CE, UL, and CSA certified, safe and reliable. Closed-loop servo system ensures operator safety through multi-level protection and reduces potential work-related injuries.
Safety
Anti-Recoil Technology
Prevent the equipment from deviating or recoiling when there is a sudden change in load.
Overload Protection
When the load exceeds the rated capacity, overload protection will be activated to prevent the equipment from lifting.
Power Loss Protection
A fail-safe load braking system locks the equipment in place in the event of a power loss.
Intelligence
Custom Programming
Set the system features entering Program Mode, such as virtual limits, lifting speed, lifting sensitivity, etc.
Input / Output Points
Control any handling device through user configurable 4 input / 2 output points on the handle.
Model Specifications
| Configuration | Model Number | Max Capacity* | Duty | Max Lifting Speed | Max Lifting Speed | Max Travel | Rated | Lifting |
kg (lbs) | m/min (ft/min) | m/min (ft/min) | m (ft) | W (hp) | Stainless Steel Wire | |||
| EIS Inline Slide Control Handle | EIS017138W16UL | 80 (176) | H4/Equivalent | 40 (131) | 36 (118) | 3.5 (11.5) | 750 (1) | 5mm, 19 strand x 7 wires |
EIS044138W16UL | 200 (441) | H4/Equivalent | 30 (98) | 27 (89) | 3.5 (11.5) | 1,500 (2) | 5mm, 19 strand x 7 wires | |
EIS066138W16UL | 300 (661) | H4/Equivalent | 15 (49) | 13.4 (44) | 3.5 (11.5) | 2,000 (2) | 5mm, 19 strand x 7 wires | |
EIS132068W18UL | 600 (1,323) | H3/Equivalent | 7.6 (25) | 6.7 (22) | 1.7 (5.6) | 2,000 (2) | 6.5mm, 19 strand x 7 wires |
